Bead
Apexing & Flipping Machine
|
The Bead Apexing & Flipping Machine is an automated system designed for
PCR tire production. It features high performance and reliability,
capable of completing the entire process¡Xfrom apex extrusion, cooling,
cutting, and application, to bead flipping and pressing¡Xfully
automatically. This machine enhances bead quality and uniformity,
reduces manual labor, and significantly boosts production efficiency. |
|
¡@ |
¡@
|
|
¡@ |
|
Model |
PHT - 038-1 |
PHT - 038-2 |
PHT - 038-3 |
|
Spec |
¡@ |
For PCR |
For LT |
For TB |
|
Bead¡@ |
Dia |
£X 330~406 mm (13~16¡¨) |
£X 381~457 mm (15~18¡¨) |
£X 500~610 mm (20~24¡¨) |
|
Width |
6 ~ 9.5 mm |
7 ~ 12 mm |
8.5 ~ 16 mm |
|
Apex¡@ |
Height |
25 ~ 55 mm |
25 ~ 55 mm |
23 ~ 40 mm |
|
Width |
5.5 ~7.0 mm |
5.5 ~ 12 mm |
9 ~ 16 mm |
|
Flipper |
Width |
40 ~ 70 mm |
40 ~ 70 mm |
70 ~ 105 mm |
|
¡@
¡@ Cold feed extruder ¡@
¡@
¡@ |
Screw |
£X 3¡¨ ( £X 75 mm ) |
|
L/D ratio |
15 : 1 |
|
Screw speed |
7 ~ 54 RPM / min |
|
Cap. |
180 ~ 230 kgs / Hr |
|
Motor |
DC 50 HP ( 37.5 KW ) / 1150 RPM |
|
Temp. control |
0 ~ 90¢XC |
|
Driving stored-material, cooling equipment |
3 zones |
3 zones |
4 zones |
|
Apex and bead ring automatic flipping device 1 group |
|
Electric control system 1 group |
|
Assemblies : Dancer stand,
Control panel, Apexing unit, Cooling festoon unit, Flipper let-off
stand, Apex
cutter & feeder |
|
¡@
¡@
JLB Slitter &
Interactive Winder ( Cord
Stripping Machine ) ¡@ |
The JLB slitter & interactive winder offers not only high efficiency but
also highly accurate slitting, making it ideal for precise cord fabric
processing and reliable winding. | ¡@ NE / NF slitter winder
¡@
 ¡@ | ¡@
| Model | PHT - 037 | Slitting cord size | W 80 mm, slitting to W 10 mm x 8 pcs | Shaft of supply roll | 38 mm ( Square ) x O.D. 110 mm x L 350 mm | O.D. of material ( Nylon cord ) | Max. 600 mm | O.D. of liner for nylon cord | Max. 250 mm | O.D. of slitter roll | Max. 300 mm | Width of rank accept each one for after cutting | Max. 320 mm | Shaft of supply roll | 38 mm ( Square ) | Speed of pulling strength | Max. 70 M/min | Thickness of slitter | 0.8 ~ 1 mm | Tolerance of slitter | + - 1 mm | Overall dimension | L 720 x W 150 x H 230 cm |
|
Passenger Tire Production Flow
Chart
|
