Demattia Flex Cracking Testing Machine

¡@

This machine is designed according to ASTM D430¡BJIS-K6301. The function is to test the flex endurance of material like rubber products, sole, PU, etc. According to the expand-cracking size of specimen to evaluate the flex-endurance of the material.

¡@

Model

PHT - 8021

Bending speed

300 ¡Ó 20 cpm

Bending angle

180¢X or 90¢X

Grip

3 sets

Reciprocate stroke

19 ~ 75 mm

Specimen size

Max. L150 x W 25 x H 6 mm

Counter

6 digits with auto brake

Crock Meter

This apparatus is used to perform rubbing tests for color fastness.

Model

PHT - 222

Rubbing shaft

2 sets

Rubbing speed

60 cpm

Specimen

125 x 50 x 50 mm

Cloth size

50 x 50 mm

Reciprocated distance

100 ¡Ó 1 mm

Rubbing shaft dia

16 mm

Load

900 g

Counter

6 digits LCD display

Abrasion Resistance ( DIN type)

This tester is used to evealute the resistance of rubbers or other elastomers during friction and wearing.

Model

PHT - 8621B

Grinding wheel

Dia 150 mm

Specimen size

Dia 16.2 x T. 6~10 mm

Speed of specimen

4.2 mm per revolution

Loading

0.25, 0.5, 1.0, 1.5, 2.0 kgs

Rotating speed

40 R.P.M.

Reference standard

DIN-53516, JIS-K6369

Akron Abrasion Tester

This tester is designed to use together with a special balance for testing the abrasive consumption for the rubber products such as tire,etc.

Model

PHT - 8022

Speed

250 ¡Ó 5 RPM or 85 ¡Ó 5 RPM

Grinding wheel

ø150 x 38 (W), Sand grit #40

Testing angles

0 - 45¢X (Adjustable)

Counter

6 digits ( Electronic setting )

Specimen

External dia 2.5" x Internal dia 1/2", T 1/2" Hardness 60 - 70¢X
or L 220 x W 12.7 x T 1.5 mm

Loading approx.

0.45 kgs or 2.73 kgs

Punch Press Tester

This machine is designed to cut a sample specimen of a specific size. The specimen can then be used for elongation, tension, aging or oil testing.

¡@

Model

PHT - 8024

Specimen cutter

1, 2, 3 or A, B ( selectable )

Working area

30 x 16 cm

Pressurization

Manual

Anvil size

15 x 7 cm

¡@

Aging Oven Tester

Make the deterioration of vulcanized rubber and plastic for figuring the changing rate of pulling and elongation before/after heating.

Model

PHT - 052

Inner size

40 x 40 x 40 cm

Heater

1.8 KW

Temperature

300 ¢XC

Motor speed

7 - 10 RPM

Motor

1/10 HP
