Product features:
This product enhances advertising effectiveness and captures attention,
builds a strong brand identity that leaves a lasting impression,
differentiates products in the market by showcasing versatility and
strengthening competitiveness, and offers a variety of colors to increase
visual appeal and boost sales.
Instructions for use:
Maintain a fixed arc direction, apply labels with a forming machine, etc
ensure tight film adhesion, and control rubber flow to prevent defects.
¡@ |
PU Prepolymer for
Elastomer
|
|
These high-performance
polyurethane elastomer systems are easy to use, come in a wide range of
Shore hardness levels, and are cost-effective for producing complex
molded parts in combination with a variety of materials.
¡@ |
|
Item
|
PHT - 5060
|
PHT - 5090 |
PHT - 5096 |
|
Content
|
2.3 ¡Ó 0.1
|
4.3 ¡Ó 0.1 |
5.8 ¡Ó 0.1 |
|
Viscosity (CPS/40 ¢XC)
|
1500 - 4000
|
7000 - 17000 |
4500 - 12500 |
|
PHR of MOCA
|
7
|
12.5 |
16.6 |
|
Pot-Life ( Min )
|
30
|
10 |
5 |
|
Hardness ( Shore ) A :
|
54 - 60
|
86 - 92 |
90 - 96 |
|
Elongation %
|
450 - 500
|
500 - 600 |
350 - 450 |
|
Tensile ( Kg / cm )
|
20 - 60
|
200 - 300 |
200 - 350 |
|
Type
|
PPG |
|
Applications
|
Industry products, etc.
|
Mechanical
parts, roll, etc. |
Heavy load rollers, deflection pulleys, etc. |
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
|
Item
|
PHT - 5100
|
PHT - 5167 |
PHT - 5160 |
|
Content
|
4.4 ¡Ó 0.1
|
6.3 ¡Ó 0.1 |
¡@ |
|
OH
|
¡@
|
¡@ |
59 ¡Ó 3 |
|
Viscosity (CPS/40 ¢XC)
|
5000 - 11000
|
2500 - 7500 |
3500 - 8500 |
|
T-80
|
¡@
|
¡@ |
8.5 |
|
PHR of MOCA
|
12.5
|
18.2 |
¡@ |
|
Pot-Life ( Min )
|
11
|
6 |
¡@ |
|
Hardness ( Shore ) A :
|
86 - 92
|
89 - 98 |
28 |
|
Elongation %
|
00 - 500 |
350 - 450 |
500 |
|
Tensile ( Kg / cm)
|
300 - 450
|
350 - 500 |
11 |
|
Type
|
PTMG
|
Polyester |
|
Applications
|
Adiprene
L - 100
|
Adiprene
L - 167 |
Solvent & chemical resistance
for printing roll, etc. |
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@
|
|
¡@
¡@
¡@
MOCA (Curing Agent)
¡@
MOCA is a curing agent
for polyurethane resins. The chlorine atoms on the benzene ring reduce
the activity of the "NH" group, thereby extending the pot life during
casting operations. ¡@ |
|
¡@
|
|
Item |
PHT - 15 |
|
Appearance |
Light yellow crystalline pill |
|
Odor |
Amine odor |
|
Boiling point |
202 ~ 214 ¢XC (3mmHg) |
|
Melting point |
98¢XC min. |
|
Vapor pressure |
1 x 10-5 mmHg ( 25 ¢XC) |
|
Flash point |
249 ¢XC |
|
Specific gravity |
1.44 ( H O =1 ) |
|
Solubility |
Insoluble in water, soluble in acetone, toluene and ethyl alcohol |
¡@
¡@
¡@
¡@
¡@ | |
Primer for
Urethanes Elastomer
This primer is
used to bond liquid urethanes to various substrates during the curing
process. It offers excellent adhesion to aluminum alloys, steel, wood,
glass, and other materials.
¡@
|
|
|
Item |
PHT - 1147 |
|
Viscosity (CPS) |
2,000 |
|
Color |
Amber |
|
Solids content (%) |
24 |
|
Specific gravity @77 F ( 25 ¢XC ) |
0.90 |
|
Weight per lb/gal. |
7.50 |
|
¡@
This
release agent is mainly used for integral skin polyurethane and rigid
foam molding. It provides excellent release performance, reduces the
need for cleaning downtime, and supports both dry and glossy surface
finishes.
¡@ |  |
|
Item |
PHT - 608 N |
|
Specification |
Concentrate. As a rule
dilute-able
1 : 10 -15 with e.g.
MC, 1,1,1,- T.C.E., lsohexane. |
|
Properties |
Sprayable, solvent based release agent. |
|
Packing |
25 kgs / pail |
¡@ |
|
¡@
 |
